60
PART 10. PARTS BREAKDOWN
ITEM # PART DESCRIPTION PART NUMBER
62 ARM INLET HW599 HC D104574
63 GASKET 3/4 OD EPDM 70A DURO SQ HOLES FAST CONNECT ARM 399/599 D104191
64 PLUG PIPE 1/2 NPT BRS SQ HD SCH40 LF D30035
65 NIPPLE TBE 3/4 NPT X 3 BRS SCH40 D10861
66 ELBOW 90 3/4 NPT CU UNS C87850 LF D11029
67 TUBE EVO GAS HW599 OUTLET REV. D D111660
68 ADAPTER 1 CMPXFNPT BRS HW599 D104272
69 MANIFOLD GAS OUT HW599 D105000
70 KIT FLG 3/4 D104922
71 VALVE GAS 1/2 BSPT HW79/599 D108737
72 NIPPLE HEX 1/2 MNPTXNPSL X 1 BRS D104271
73 ADAPTER RDCR 3/4 CMP X 1/2 FNPT BRS HW599 GAS D104275
74 MANIFOLD GAS INL HW599 D105002
75 TRANSDUCER PRESS 1/4 MNPT +/-1 PSI D104962
76 GASKET 2.8 OD EPDM 60 DURO EVO 559 GAS MAN D104190
77 BURNER INL HW79-399 AIR/GAS D112959
78 BURNER PIPE HW299 70MM X 210MM D113711
BURNER PIPE HW399 70MM X 296MM D113050
79 GASKET 3.27 OD EPDM 70A HW179 GAS/AIR INL PIP D106935
80 BLOWER 7.6 240VAC STD OUTPUT ENHANCED FAN NAU D105628
81 COVER VENTURI BURNER AIR/GAS MXG HW299 D113733
COVER VENTURI BURNER AIR/GAS MXG HW399 D113051
82 NIPPLE TOE 3/4 BPST X 4.467 SCH40 CS A53 TF HW299-399 GAS OUT
CTD ZINC AND CLEAR 299/399 GAS OUTLET TUBE
D114865
83 KIT FLG 3/4 NPT ELBOW D114078
84 PIPE GAS INL HW399HOT D116288
85 GASKET 2.4 OD EPDM 60 DURO INL GAS MAN D113692
85 GASKET 2.4 OD EPDM 60 DURO INL GAS MAN D113692
