Document #101-0204 13 10/21/2011
CAUTION: WHEN MOUNTING THE GATE, THE SERVICE
DOOR SHOULD BE FACING INTO THE LANE IF NOT
MOUNTED CORRECTLY THE ARM WILL CLOSE IN THE
WRONG DIRECTION. WHEN CORRECTED THE LOOP
WILL NOT BE IN THE PROPER POSITION
Gate Orientation
SERVICE DOO
R
FACING LANE
TRAFFIC
FLOW
