LED Indicators
LED State Indication
Status Blinking for POST (Yellow) When power switched on, the Status
indicator will flash five times, and then on
100Mbps On (Green) LAN Port has a valid network connection
at 100Mbps
10Mbps On (Orange) LAN Port has a valid network connection
at 10Mbps
On (Green) Connect with USB 2.0 printer USB
On (Orange) Connect with USB 1.1 printer
Before you start, you should prepare the following items:
• One Windows-based computer with print server setup CD
• One printer with a USB port
• One USB printer cable
Hardware Installation
To install the print server, you need to complete these steps:
1. Confirm that your printer USB port works well.
2. Connect the print server to the network and printer, and plug in the print server.
Follow these instructions to install the print servers, please refer to any peripheral
you are connecting to the print server:
1. Turn off the printer’s power.
2. Connect the print server to your printer with the USB cable.
3. Turn the printer’s power on.
4. Plug the AC power adapter into the power connector on the print server.
5. Wait 10 seconds until all the LEDs have stopped flashing.
Note: The Status LED should be flash five times during POST. If not, please contact your
local dealer for repair or replacement.
