6
Return Line Adjustments
Important
The cleaner must move randomly throughout the pool. Water circulating at the surface
will infl uence the hose thus limiting Cleaner’s coverage.
Adjust Return Line Flow as described in diagrams below.
To adjust the Eyeball Diverters;
loosen the lock ring and redirect the Eyeball Diverters slightly downwards and also
try different directions to see what works best in your pool. allow time for the body
of water to settle into new pattern.
BEFORE ADJUSTMENT
AFTER ADJUSTMENT
WEIV EDISWEIV POT
TOP VIEW
SIDE VIEW
