HAMPTON BAY GAZEBO YG188-BN User Manual

Part
Part
A
B
C
D
E
F
G
H
I
J
K
Description
Description
Mounting bracket (preassembled)
Canopy ring (preassembled)
Canopy
Canopy bottom cover (preassembled)
Hanger ball/downrod assembly
Coupling cover
Fan motor assembly
Blade
Blade arm
Light kit
Glass shade
Part
Part
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
KK
LL
MM
Description
Description
Plastic wire nut
Canopy mounting screws with lock washer (preassembled)
Blade attachment screw and rubber washer
Blade arm screw and lock washer (preassembled)
Clevis pin (preassembled)
Cotter pin (preassembled)
Collar setscrew (preassembled)
Collar mounting screw with lock washer (preassembled)
Light kit mounting screw (preassembled)
9.5 Watt LED medium base bulb
Pull chain and fob
Plastic plug
Balance kit
Service Parts
A
AA
HH
II
JJ
KK
LL
MM
BB
CC
DD
EE
FF
GG
H
I
J
K
E
F
G
19 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
B
C
D

HAMPTON BAY GAZEBO YG188-BN Specifications

General

Brand	Hampton Bay
Model	YG188-BN
Type	Ceiling Fan
Fan Diameter (in.)	52
Blade Span	52 inches
Number of Blades	5
Motor Speed	3-speed
Mounting Type	Downrod
Material	Metal
Finish	Brushed Nickel
Light Kit Included	Yes
Light Type	LED
Warranty	Limited Lifetime
