SAFETY INSTRUCTIONS
• Read all these instructions carefully before installing and connecting the product.
• Do not attempt to dismantle or repair the product – it does not contain any parts that can be
repaired by the user.
• The product should be installed indoors. Do not expose the product to rain, snow or moisture,
and make sure that water cannot get into the product.
• Install the product in a well ventilated area. The cooling ns on the product can get very hot
when in use – risk of burn injuries.
• The product should be connected via a fuse/miniature circuit breaker with the correct tripping
current.
• Switch o and disconnect all solar panels and batteries before installing and adjusting the
charge controller.
• Check that the power connections are rmly tightened to minimise loss of power and the risk of
overheating.
SYMBOLS
Read the instructions.
Approved in accordance with the relevant directives.
Recycle discarded product in accordance with local regulations.
TECHNICAL DATA
Rated voltage* (auto) 12/24 VDC
Rated current, charging 20 A
Rated current, discharging 20 A
Voltage interval, battery 8 – 32 V
Max open circuit voltage, solar panel, at lowest ambient temperature 100 V
Max open circuit voltage, solar panel, at ambient temperature 25°C 92 V
Voltage interval for MPP (Battery voltage + 2 V)
~
72 V
Max input power at 12 V 260W
Max input power at 24 V 520W
Consumption ≤ 12 mA
Voltage drop, discharge circuit ≤ 0.23 V
Temperature compensation coecient** -3 mV/°C/2 V (standard setting)
Earth Minus (-)
Protection rating IP30
