Hamworthy F40W - Page 10

HAMWORTHY HEATING LTD
4
FLEET W series 500001211/F
Figure 2.4 - Two boiler arrangement showing frame, flue header, water pipework and low loss header
Figure 2.5 - Two boiler arrangement showing frame, flue header, water pipework and 6 port
(multi secondary circuit) low loss header.
Open flue with air
drawn from plant
room
Open flue with air
drawn from plant
room
