3.0 SIZE AND SPACE REQUIREMENTS
3.1 The Fleet boiler range has been designed to utilise minimum wall space, therefore it is important that the plantroom
has sufficient ceiling height to allow for installation and connection to the flue system allowing for sufficient access at sides
and below boiler for pipework connections. See Figure 3.1
Figure 3.1.1 - Dimensions for individual flues - refer to table Figure 3.1.3
Side View
Side Flue Exi
t
Side View
Rear Flue Exit
Front View
Side Flue Exi
t
300 min
A
B
Gas - 470
Electric - 490
35
D
45
View on underside
Condense - 345
Flow - 270
Return - 120
Safety valve - 195
9
00
m
in
clearance
540
540
560 crs
20
134
150
Gland
holes
21mm * 2off
B
B
540
150
Plan View
C
Flue Dia.
930
134
