HAMWORTHY HEATING LTD
9
FLEET W series 500001211/F
Figure 3.2.5 – Four boilers -
Refer to table
Figure 3.2.4 – Three boilers -
Refer to table 3.2.5
Dimension F40-100W F125-150W
A (mm) 233 304
B DN50 - PN16 DN65 - PN16
Boiler
C R 1½” R2”
1680
540
2090
20
540215
85
1850 Nom.
2170 Nom.
600 min.
2240
540
2650
20
540
1850 Nom.
2210 Nom.
300
150
600 min.
