Quick Check® 600/800 Series User’s Guide 3 - 3
Symbology Specifications
* The message length specification for each symbology is listed. Although you can enter
any value between 0 and 255, the unit does not decode more than the values indicated by
the specification.
Symbology
EAN/UPC
Code 39
Interleaved
2 of 5
Code 128
Code 93
Codabar
Code 11
Parameters (defaults are in bold)
Enable: On or off
Magnification factor: (080/085/090/100/105/110/115/120/130/140/150/
160/180/200)
Expand U.P.C.-EO: Yes or No
Enable: On or off
Check Character: None or Checked
Fixed W/N: None or a value between 1.4 and 3.9 +
0.2
Fixed Msg Len*: None or a value between 1 and 49 characters
Enable: On or off
Check Digit: None or Checked
Fixed W/N: None or a value between 1.4 and 3.9 +
0.2
Fixed Msg Len*: None or a value between 1 and 78 digits
Enable: On or off
Modes Shown? Yes or No
Fixed Msg Len*: None or a value between 1 and 70 characters
Enable: On or off
Fixed Msg Len*: None or a value between 1 and 80 characters (from
Code 39 set)
Enable: On or off
Character Font & Tolerances: Trad’l,”USS” or ISO/IEC’83
Fixed W/N: None or a value between 1.4 and 3.9 +
0.2
Fixed Msg Len*: None or a value between 1 and 61 digits
Enable: On or off
1 or 2 check digits
Fixed Msg Len*: None or a value between 1 and 80 digits
Code 16K
Code 49
MSI Code
IATA 2 of 5
Regular 2 of 5
Enable: On or Off
Modes Shown? Yes or No
Fixed Msg Len*: None or up to 154 characters, full symbol
Enable: On or Off
Fixed Msg Len*: None or up to 49 alpha (81 numeric characters, full
symbol
Enable: On or Off
User Check: None, Mod 10 or Mod 11
Fixed Msg Len*: None or a value between 1 and 50 digits
Enable: Yes or No
Enable: Yes or No
Enable: Checked or None
