Quick Check® 600/800 Series User’s Guide 5 - 5
QCP and QCHSP Printouts
***Quick Check 600***
660 nm, 06 mil Scanner
Interleaved 2/5
123456
- Extended Accuracy! -
Avg Bar Err = -.05X OK!
Wide/Nar Ratio = 2.5 OK!
Decodability = 53% <B>
Symbol Total = 055”X”
Prnt Contr Sig = 92% OK!
Reflect(Light) = 86% OK!
Reflect(Dark) = 05% OK!
Symbol Contrst = 81% <A>
R(min)/R(max) = 06% <A>
Modulation = 91% <A>
EdgeContr(min) = 73% <A>
“Defects” = 05% <A>
Message Length = 06 OK!
— No Check Character —
Bar Growth IN TOL
“P C S” OK
Traditional Tests -PASS-
Format Tests -PASS-
ISO/IEC Parameters <B>
Add’l P/F Checks <P>
Format Checks <P>
Profile Quality Grade <B>
Passing Level: ISO/IEC <C>
==> ScanProfile PASSES
Name:
Date:
Symbol Grade
Avg. 4.0 => A/06/660
After 002 of 010 Scans
