HandI Move 2540 - Fitting top cover

4.3. Fitting top cover
1. Push the motorband through the slot and fit the top cover (G) onto
the portable motor.
2. Ensure the cover is correctly seated.
3. Tighten the top cover with the screws (F).
4. Push the handgrip (E) onto the shaft.
5. Position the plate (D) on the other side
6. Push the washer (C) over the bolt (B’).
7. Screw on the locknuts (B).
8. Refit the end caps (A) on the handgrip.
p. 11
2540 / 2545 • REPAIR
A
E
D
C
B
A
WG
F
F
B’
