Use of the wheelchair
19
5.5 Adjustment options
Adjustment options are those parts of a wheelchair that can be adjusted by the user
without the use of tools. The Alex can be ordered with the following adjustment options:
Mechanical adjustment options
• Comfort legrests SEDEO
• Swing-away joystick holder SEDEO
• Headrest SEDEO
Electrical adjustment options
• Electrical tilt adjustment CONTROLLER
• Electrical high/low option CONTROLLER
• Electrical backrest adjustment CONTROLLER
• Electrical legrests CONTROLLER
Figure 8.2
5.6 Freewheel switch: pushing the wheelchair
The wheelchair can also be moved by pushing. For this purpose, the motors must be
disengaged. This is done with a freewheel switch; one for each motor.
Figure 5.1: Left: free wheel switch in ‘push’ position; Right: ‘drive’ position
• Never drive down stairs in a wheelchair.
• Do not drive off obstacles higher than 6 cm.
