How to fix Joystick Calibration Error on Handicare Mobility Aid?
If your Handicare Mobility Aid displays 'Joystick Calibration Error', it means the Joystick Calibration process has not been successful. Enter OBP and attempt calibration. If the error persists, the Joystick Module may be defective.
What does it mean if ON/OFF light flashes 3 times on Handicare Mobility Aid?
If the ON/OFF light on your Handicare Mobility Aid flashes 3 times, it could be due to several reasons related to the m1 motor. The m1 motor connection might be faulty or loose, so check the connection and secure it. The m1 motor itself could be defective and need replacement. There might also be a short circuit in the m1 motor connections, requiring correction. Additionally, a defective power module output could be the cause. Check the motor for any defects, as a power module output typically becomes defective due to a motor issue. Replace the power module only if the fault occurs immediately upon switching the unit on. If the fault occurs when you start driving, the entire left-hand motor circuit is likely causing the fault, in which case you should replace the entire drive unit concerne...
How do I fix a Joystick Calibration Error on my Handicare Scooter?
A Joystick Calibration Error on your Handicare Scooter means the joystick calibration process was unsuccessful. Enter OBP and attempt calibration. If the error persists, the Joystick Module may be defective.
What does it mean if ON/OFF light flashes 4 times on Handicare Mobility Aid?
If the ON/OFF light on your Handicare Mobility Aid flashes 4 times, the cause may be related to the m2 motor. The m2 motor connection could be faulty or loose, so check the connection and secure it. The m2 motor itself might be defective and need replacement. There might also be a short circuit in the m2 motor connections, requiring correction. Additionally, a defective power module output could be the cause. Check the motor for any defects, as a power module output typically becomes defective due to a motor issue. Replace the power module only if the fault occurs immediately upon switching the unit on. If the fault occurs when you start driving, the entire left-hand motor circuit is likely causing the fault, in which case you should replace the entire drive unit concerned.
Why is the ON/OFF light flashing four times on my Handicare Scooter?
If the ON/OFF light flashes four times on your Handicare Scooter, it could be due to a faulty connection or a defective m2 motor. Check the motor connections and cabling. If the connections are fine, the m2 motor may need to be replaced.
Why does Handicare Mobility Aid show Low Battery?
If your Handicare Mobility Aid displays a 'Low Battery' message, it means the control system has detected that the battery voltage has fallen below 16V. Check the condition of the batteries and their connections to the control system. If the issue persists after checking the batteries and connections, the Power Module may be defective.
What does Left Indicator Lamp Short mean on Handicare Mobility Aid?
If your Handicare Mobility Aid displays 'Left Indicator Lamp Short', it means the control system has detected a short in either of the Indicator Circuits. Check the indicators, cables, and connections to the control system. If the trip persists, the ISM may be defective.
What does PM Memory Error mean on my Handicare Scooter?
A PM Memory Error on your Handicare Scooter is a specific Power Module based trip. Check all cables and connections.
What does Module Error mean on my Handicare Scooter?
The 'Module Error' message on your Handicare Scooter indicates that the control system has detected a trip within a specific module. Check all cables and connections, then cycle the power.
What does PM Memory Error mean on Handicare Mobility Aid?
If your Handicare Mobility Aid displays 'PM Memory Error', it is a specific Power Module-based trip. Check all cables and connections. Using the R-net PC Programmer, re-program the control system with either the most current specific program file for the wheelchair or the manufacturer's original programming file. If the trip persists, the PM may be defective.
Explains the purpose and scope of the service manual for mechanics.
Details the information found on the product's identification plate.
Explains warning and reference symbols used in the manual for clear communication.
Lists Puma 20 options that reduce the maximum user weight on a Puma 40 carrier.
Specifies requirements for service technicians performing repairs.
Outlines general safety information, temperature warnings, and interference precautions.
Illustrates and explains the meaning of various decals found on the wheelchair.
Lists mechanical tools required for settings and maintenance tasks.
Lists tools required for electronic settings and programming.
Explains how to use the parts lists for ordering replacement components.
Provides an overview of carrier and seat components with their corresponding page numbers.
Lists wiring harnesses and electronic modules for the Shark system.
Lists wiring harnesses and electronic modules for the R-net system.
Lists wiring harnesses and electronic modules for the DX2 system.
Lists wiring harnesses and electronic modules for the VR-2 system.
Details the regular maintenance schedule for the wheelchair, specifying tasks and responsibilities.
Introduces instructions for assembly, replacement, and adjustment of wheelchair components.
Guides on replacing Puma 20 motors, including compatibility and programming.
Details the procedure for converting drive direction from FWD to RWD and vice versa.
Provides steps for replacing carbon brushes in the motor assembly.
Explains the process for replacing the indoor/outdoor drive wheels.
Details the procedure for replacing the castor wheels.
Outlines steps for replacing the castor fork assembly.
Provides instructions for installing the direct access accessory.
Guides on installing the attendant steering system.
Details the procedure for replacing the wheelchair batteries, including safety precautions.
Explains how to replace the power module unit.
Details the process for adjusting the wheelchair's seating height.
Explains how to adjust the wheelchair's center of gravity for stability.
Explains how to adjust the electrical seat tilt angles.
Provides tables detailing seat tilt limitations based on various configurations.
Offers troubleshooting steps for castor wheel shimmy issues.
Lists common faults and remedies for the Shark system.
Lists common faults and remedies for the R-net system.
Lists common faults and remedies for the DX2 system.
Lists flash codes and their meanings for the DX2 Actuator Module.
Lists common faults and remedies for the VR-2 system.
Lists relevant CE directives and standards the product complies with.
Provides general technical specifications like battery details and dimensions.
Lists technical specifications for various Puma models (40/20, Sedeo Pro+/Pro/Lite/EasyFit).
Shows system diagrams for various control modules like Shark, DX2, R-net, VR-2.
Shows system diagrams for Shark control modules.
Shows system diagrams for DX2 control modules.
Shows system diagrams for R-net control modules.
Shows system diagrams for VR-2 control modules.
Provides definitions for terms used in the warranty section.
Outlines the warranty periods for different parts and components of the power wheelchairs.
General| Brand | Handicare |
|---|---|
| Model | PUMA 40 |
| Category | Wheelchair |
| Language | English |
