Operating instructions
39
Position of the wheels
Changing the position of the
wheels may affect the stability of
the wheelchair. Check the
stability of the chair and make
sure the anti-tip brackets are
well adjusted.
Check the brake.
12”/16” rear wheels
1. Put the frame on a solid base, so
that the wheels are off the ground.
2. Remove the manual control (A).
3. Remove the foot bracket (B).
4. Loosen the nut (C) with a 19mm
spanner.
5. Move the wheel into the desired
position.
6. Tighten the nut (C) securely.
20”/22”/24” rear wheels
1. Put the frame on a solid base, so
that the wheels are off the ground.
2. Loosen the bolts (A) with a 19 mm
spanner and remove them.
3. Move the wheel plate (B) into the
desired position.
4. Tighten the bolts (A) securely.
Anti-tip brackets
1. Loosen the bolts (B).
2. Put the anti-tip brackets in the
desired position.
3. Tighten the bolts (B) securely.
Check if the anti-tip brackets work
properly.
