Technical specifications
43
5 Technical specifications
Description
Diameter rear wheels 12” / 16 20” / 22” / 24”
Diameter front wheel 7” 7”
Tyre pressure rear wheels 2,5 Bar 7,5 Bar
Max. user weight 160 kg 160 kg
Total length 1040 mm 1040 mm
Total width 625 mm 660-700-740 mm
Total weight 40 kg 40 kg
Total weight of the heaviest part 26 kg 28 kg
Static stability downward 15° 15°
Static stability upward 15° 15°
Static stability sideways 15° 15°
Seat tilt adjustment 30° 30°
Seat angle 0 - 6° 0 - 6°
Effective seat depth 420 - 600 mm 420 - 600 mm
Effective seat width 400 - 540 mm 400 - 540 mm
Seat height front 390 - 540 mm 390 - 540 mm
Backrest angle 89 - 128° 89 - 128°
Backrest height 500 - 640 mm 500 - 640 mm
Lower leg length 360 - 530 mm 360 - 530 mm
Armrest height 170 - 290 mm 170 - 290 mm
Front armrest (30 cm pad) to backrest 360 - 500 mm 360 - 500 mm
Front armrest (40 cm pad) to backrest 390 - 500 mm 390 - 500 mm
Minimum turning radius 810 mm 810 mm
Ground clearance 70 mm 70 mm
Push bracket height 920 - 1250 mm 920 - 1250 mm
