Operating instructions
40
Brake
For the various wheel sizes, specific
holes are available.
Readjust the brake, so that the
brake power is sufficient.
1. Loosen the Allen bolt (D) a few
turns with a 15 mm Allen key.
2. Put the brake in the desired
position.
3. Tighten the Allen bolt (D) securely.
Check the brake.
3.11 Adjustment options (user)
Seat tilt adjustment
1. Apply the wheelchair brake.
2. Grasp the push handles of the
push bracket and squeeze the
handle (A).
3. Push the push handles downward
until the desired angle is reached.
