Operating instructions
41
Manually recling backrest (by
attendant)
1. Squeeze (A).
2. Adjust (B) to the desired position.
Keep squeezing (A)
3. Release (A).
Manually recling backrest (by
user)
1. Squeeze (A).
2. Lean forwards or backwards to
adjust (B) to the desired position.
Keep squeezing (A).
3. Release (A).
Push handle height
1. Loosen (A) by one turn.
2. Slide (B) into the desired position.
3. Tighten (A).
The seat tilt adjustment cable
should not be too tight.
