Technical specifications
23
4 Technical specifications
Type: PowerSupport Ibis
Tested by: TNO, in conformity with EN 12184 (1999) class B, for indoor and outdoor
use.
Weight test dummy: 125 kg.
IBIS with Power Support
Weight: 55.6 kg
Turning radius: 770 mm
Maximum width: min 687, max 720mm
Static stability for IBIS with Power Support
Upward: 11°
Downward: 10°
Sideways: 15°
Dynamic stability upward: 9°
Recommended maximum angle on a slope upward and downward: 6°.
Range: 18-20 km
Maximum speed: 5 km/h
The PowerSupport has its own battery system. The battery cover is not to be opened.
Battery type: NiMH, 24 V
Battery capacity: 9 Ah
Charging time: 2 hours for a full charge.
Specifications of a suitable battery charger:
Input 220V AC
Output 24 V DC, 3.4 A +/- 5%
XLR connector 4-pin
A suitable battery charger can be provided by Handicare
Tyre size: 12.5x2 1/4’’
Tyre pressure: 2.7 Bar
