WARNING: Some photographs used in the following pages show guards or shields
removed for clarification. NEVER operate machine until these guards or shields are
in proper operating position.
-11-
UNLOADING (Continued)
8. If it is necessary to trip the stop mechanism and disengage forage wagon drive before the wagon is
empty, restart unloading by engaging clutch lever (A). (Shown on Page 10)
9. Clean out position is for cleaning out forage box at the end of load.
10. When forage box is empty, return control lever (B) to beater disengage position while PTO is still
running. (Shown on Page 10)
11. Move control lever (A) to disengage position. (Shown on Page 10)
12. Disconnect PTO and place in convenient holder for field and road use.
EMERGENCY STOP
A
In case of an emergency, pushing emer-
gency stop panel or pulling the safety
cable will stop cross conveyor, beaters,
and main aprons. PTO will continue to
rotate. Trip emergency stop occasionally
to insure proper function.
A. Emergency Stop Panel
B. Emergency Stop Cable
B
WHEN OPERATING FORAGE BOX
AS A REAR UNLOAD, OPERATOR
SHOULD REMAIN IN TRACTOR
SEAT AND KEEP ALL OTHERS
WELL CLEAR.
EMERGENCY STOP DOES NOT
STOP FORAGE BOX WHEN BEING
OPERATED AS A REAR UNLOAD.
1494Q
-50-
FIGURE 12
