Model CPCD20N-RW10 CPCD25N-RW10 CPCD30N-RW10
Rated capacity Kg 2000 2500 3000
Load center mm 500 500 500
Max. lifting height mm 3000 3000 3000
Free lifting height mm 150 150 155
Max lifting speed mm/s 410 410 380
Tilting angle F/B 6°/12° 6°/12° 6°/12°
/ / /
Max traveling
speed Km/h
hydraulic 20．5 20．5 19
Ground clearance mm 105 105 130
Min turning radius mm 2175 2235 2375
Max grade ability % 20 18 18
wheelbase mm 1650 1650 1760
Wheel thread (F/R)mm 965/970 965/970 1005/975
Service weight Kg 3440 3765 4255
Overall dimension(L×W×H)
(including forks)
3600×1155×2120 3675×1155×2120 3820×1225×2150
Tyre (F/R)
7.00-12-12PR
6.00-9-10PR
7.00-12-12PR
6.00-9-10PR
28×9-15-12PR/2
6.50-10-10PR/2
Voltage/Capacity Ah 12/90/20h 12/90/20h 12/90/20h
type ISUZU C240PKJ-30
Rated
capacity/rpm
34.5 KW/2500r/min
Max torque/rpm 139.3N·m/1800 r/min
Engine
Displacement cc 2369
