Model
CPCD20N-RW27 CPCD25N-RW27
Rated capacity Kg 2000 2500
Load center mm 500
Max. lifting height mm 3000
Free lifting height mm 150
Max lifting speed mm/s，full load 510 580
Tilting angle F/B 6°/12°
/
Max traveling speed Km/h
hydraulic 20.5
Ground clearance mm 105
Min turning radius mm 2175 2235
Grade full load % 25
wheelbase mm 1650
Wheel thread (F/R) mm 965/970
Service weight Kg 3760
2t 2525×1155×2120
Overall dimension(L×W×H)
(exclusive forks)
2.5t 2600×1155×2120
Tyre (F/R)
7.00-12-12PR/2
6.00-9-10PR/2
Voltage/Capacity Ah 12/100/20h
type
A498BT1-1 Diesel
Displacement cc 3168
Rated capacity/rpm 45KW/2500r/min
Diesel
Max torque/rpm 193N·m/ 1800 r/min
