79
Model
CPCD30N-RW33M
CPCD35N-RW33M
Rated capacity Kg 3000 3500
Load center mm 500
Max. lifting height mm 3000
Free lifting height mm 155
Max lifting speed mm/s，full
load
460 370
Tilting angle F/B 6°/12°
mechanica
l
/
Max traveling
speed Km/h
hydraulic 20
Ground clearance mm 130
Min turning radius
mm
2375 2415
3t 20
Grade full
load %
3.5t 20
wheelbase mm 1760
Wheel thread (F/R)mm 1005/973
3t 4280
Service weight
Kg
3.5t 4555
Overall dimension(L×W×H)
(including forks)
3820×1225×2150（3t）
3870×1225×2150（3.5t）
Tyre (F/R)
28×9-15-12PR/2
6.50-10-10PR/2
Voltage/Capacity Ah 12/100/20h
type
YANMAR 4TNE98-BQFLC diesel
Displacement cc 3319
Rated capacity/rpm 44.3kW/2300r/min
Diesel
Max torque/rpm 206N·m/ 1700 r/min
