HANKISON SPX HES Series User Manual

41
Phone: 724-745-1555
FAX: 724-745-6040
Email: hankison.americas.am@spx.com
Web: www.spx.com/hankison
MAINTENANCE KITS
MODEL 800 1000 1250 1500 1750 2000 2500 3000
Moisture Separator Filter
(includes separator elements & drain rebuild kit)
HESMK27D2 HESMK27D2 HESMK27D2 HESMK27D2 HESMK28D2 HESMK28D2 HESMK28D2 HESMK28D2
Optional Oil Removal Filter
(includes separator elements, oil removal elements & drain rebuild kit)
HESMK47D2 HESMK47D2 HESMK47D2 HESMK47D2 HESMK48D2 HESMK48D2 HESMK48D2 HESMK48D2
Rebuild Kit - Automatic Drain 7428278 7428278 7428278 7428278 7428278 7428278 7428278 7428278
REPLACEMENT PARTS: Water-Cooled Units
REPLACEMENT PARTS
ID# PARTS DESCRIPTION 800 1000 1250 1500 1750 2000 2500 3000
1 Refrigerant Type (see Serial Tag for charge amount) R-404a R-404a R-404a R-404a R-404a R-404a R-404a R-404a
2 Compressor - Digital Scroll 3221280 3221281 3221281 3221280 3221280 3221281 3221281 3221281
3 Compressor - Fixed Scroll N/A N/A N/A 3221282 3221282 3221282 3210948 3210948
4 Condenser 3223341 3223341 3223342 3223343 3223346 3223346 3223346 3223345
5 Contactor - Compressor - Digital Scroll
1
5002926 5002926 5002926 5002926 5002926 5002926 5002926 5002926
6 Contactor - Compressor - Fixed Scroll
1
N/A N/A N/A 5002926 5002926 5002926 5002926 5002926
7 Auxiliary Contacts - Compressor
1
7427939 7427939 7427939 7427939 7427939 7427939 7427939 7427939
9 Control Board - Digital Scroll Control
1
7442633 7442633 7442633 7442633 7442633 7442633 7442633 7442633
10 Disconnect Switch 3246083 3246083 3246083 3246083 3246083 3246083 3246083 3246083
11 Filter/Dryer - Liquid Line 3223812 3223812 3223812 3223812 3243615 3243615 3243616 3243616
12 Fuse - Control Board
1
5002943 5002943 5002943 5002943 5002943 5002943 5002943 5002943
13 Fuse - Control Transformer - Primary
1
3246089 3246089 3246089 3246089 3246089 3246089 3246089 3246089
14 Fuse - Control Transformer - Secondary
1
3246090 3246090 3246090 3246090 3246090 3246090 3246090 3246090
15 Fuse - Crankcase Heater
1
3246089 3246089 3246089 3246089 3246089 3246089 3246089 3246089
16 Heater, Crankcase 4010508 4010508 4010508 4010508 4010508 4010508 4010508 4010508
17 Motor Starter Protector - Compressor - Digital
1
5003506 5003506 5003506 5003506 5003506 5003506 5003506 5003506
18 Motor Starter Protector - Compressor - Fixed
1
5003506 5003506 5003506 5003506 5003506 5003506 5003506 5003506
19 Motor Starter Protector - Fan
1
3246077 3246077 3246077 3246078 3246078 3246078 3246078 3246079
20 Relay - High Pressure Cut-out
1
3246088 3246088 3246088 3246088 3246088 3246088 3246088 3246088
21 Replacement Screen - Water Strainer 3230673 3230673 3230662 3230662 3230664 3230664 3230664 3230664
22 Sensor - Temperature
1
5007289 5007289 5007289 5007289 5007289 5007289 5007289 5007289
25 Strainer - Water 4009635 4009635 4009636 4009636 4009637 4009637 4009637 4009637
26 Switch - High Pressure Cut-out 3230771 3230771 3230771 3230771 3230771 3230771 3230771 3230771
27 Switch - Low Pressure Cut-out 3230769 3230769 3230769 3230769 3230769 3230769 3230769 3230769
29 Transformer - Control
1
3246082 3246082 3246082 3246082 3246082 3246082 3246082 3246082
30 Valve - Automatic Drain (complete) 7428268 7428268 7428268 7428268 7428268 7428268 7428268 7428268
31 Valve - Solenoid - Digital Scroll 3232517 3232517 3232517 3232517 3232517 3232517 3232517 3232517
32
Valve - Solenoid Assembly - Digital Scroll
(includes solenoid valve and sound attenuation volumes)
3219039 3219039 3219039 3219039 3219039 3219039 3219039 3219039
33 Valve - Thermostatic Expansion (TXV) 3232550 3232550 3232550 3232550 3232532 3232532 3232533 3232533
34 Valve - Water Regulating 4006391 4006391 4006392 4006392 4006393 4006393 4006393 4006393
230/3/60 Units Only
35 Main Transformer - 230/460
1
3230908 3230906 3230906 3230906 3230906 3230896 3230896 3230896
575/3/60 Units Only
36 Main Transformer - 575/460
1
3230907 3230907 3230907 3230895 3230895 3230908 3230908 3230908
1
Items 5, 6, 7, 9, 12, 13, 14, 15, 17, 18, 19, 20, 22, 29, 35, and 36 are located in the electrical enclosure located behind the control panel. Refer to the appropriate Electrical Schematic to identify part.
2
NOTE: Consult factory with the dryer serial number when ordering Item 9, Control Board.
