HANKISON SPX HES800 - User Manual

48 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

HES Series

Energy Saving Refrigerated Type Compressed Air Dryers

Models: HES800, HES1000, HES1250, HES1500, HES1750, HES2000, HES2500, HES3000

FORM NO.: 5001364 REVISION: 04/2015 READ AND UNDERSTAND THIS MANUAL PRIOR TO OPERATING OR SERVICING THIS PRODUCT.

INSTRUCTION MANUAL

Table of Contents

Questions and Answers

M
mkleinAug 17, 2025
How to fix water downstream of HANKISON SPX HES800?
- G
  Gail WatkinsAug 18, 2025
  If there's water downstream of your HANKISON Dehumidifier, try these steps: * Blow out the system with dry air. * Check the valve positions and ensure they're correct. * Verify the connections are properly made. * Insulate or heat trace any air lines exposed to low temperatures, or use dry air to lower the dew point. * Install a separator ahead of the dehumidifier. Also, refer to section C for additional troubleshooting steps.
T
Timothy LewisAug 20, 2025
What to do if HANKISON SPX HES800 Dehumidifier's ambient temperature is too high?
- F
  flynndavidAug 20, 2025
  If the ambient temperature is too high, the condenser fins are clogged, there's obstructed flow across the condenser, or the fan motor or fan control switch is faulty in your HANKISON Dehumidifier, check the air temperature 6 inches in front of the condenser. Clean the condenser and ensure free airflow. Also, inspect the fan and switch operation.
N
Nancy ComptonAug 22, 2025
How to resolve high pressure drop across HANKISON SPX HES800 Dehumidifier?
- P
  pbrownAug 22, 2025
  To address a high pressure drop across your HANKISON Dehumidifier, you can check the flow rate and replace the filter element. Also, refer to section C for additional guidance.
A
austinjohnsonAug 25, 2025
What to do if the service interval specified has elapsed on HANKISON SPX HES800 Dehumidifier?
- T
  Terrance MontgomeryAug 26, 2025
  If the service interval specified for your HANKISON Dehumidifier has elapsed, perform the scheduled service.
C
Christopher AndersonAug 27, 2025
What to do when HANKISON Dehumidifier shows control system error?
- L
  Lisa MillerAug 27, 2025
  If you encounter a control system error with your HANKISON Dehumidifier, contact a qualified technician or the manufacturer’s service department for assistance.
C
Christian SimsAug 30, 2025
What to do if HANKISON SPX HES800 drain line restricted or frozen?
- D
  David KirkAug 30, 2025
  If the drain line of your HANKISON Dehumidifier is restricted or frozen, open the drain line to resolve the issue.
C
Carol NorrisSep 1, 2025
What to do if HANKISON SPX HES800 is overloaded?
- J
  Joshua HollandSep 1, 2025
  If your HANKISON Dehumidifier is overloaded, check the compressed air inlet flow, temperature, and pressure.
J
John GutierrezSep 4, 2025
What to do if HANKISON SPX HES800 Dehumidifier drain mechanism faulty?
- M
  Matthew ChandlerSep 4, 2025
  If the drain mechanism of your HANKISON Dehumidifier is faulty, check the drain by pressing the “Push to Test” button on the control panel. If it's still faulty, isolate the drain and rebuild the automatic drain.
L
Laura CisnerosSep 6, 2025
What to do if high refrigerant pressure occurs in HANKISON SPX HES800?
- D
  Diana CaldwellSep 7, 2025
  If you are experiencing high refrigerant pressure that requires manual reset on your HANKISON Dehumidifier, check the current command status, the power to the compressor, and the display for any fault indicators.
M
matthew47Sep 9, 2025
What to do if HANKISON Dehumidifier has low refrigerant charge?
- W
  William ShahSep 9, 2025
  If your HANKISON Dehumidifier has a low refrigerant charge, check the system pressures and temperatures to diagnose the issue.
