REPLACEMENT PARTS
ID# PARTS DESCRIPTION 800 1000 1250 1500 1750 2000 2500 3000
1 Refrigerant Type (see Serial Tag for charge amount) R-404a R-404a R-404a R-404a R-404a R-404a R-404a R-404a
2 Compressor - Digital Scroll 3221280 3221281 3221281 3221280 3221280 3221281 3221281 3221281
3 Compressor - Fixed Scroll N/A N/A N/A 3221282 3221282 3221282 3210948 3210948
4 Condenser Assembly (includes condenser and fans) 5000763 5000763 5000764 5000765 5000766 5000766 5000767 5000768
5 Contactor - Compressor - Digital Scroll
1
5002926 5002926 5002926 5002926 5002926 5002926 5002926 5002926
6 Contactor - Compressor - Fixed Scroll
1
N/A N/A N/A 5002926 5002926 5002926 5002926 5002926
7 Contactor - Fan Motor
1
5002926 5002926 5002926 5002926 5002926 5002926 5002926 5002926
8 Auxiliary Contacts - Compressor
1
7427939 7427939 7427939 7427939 7427939 7427939 7427939 7427939
10 Control Board - Digital Scroll Control
1, 2
7442633 7442633 7442633 7442633 7442633 7442633 7442633 7442633
11 Disconnect Switch 3246083 3246083 3246083 3246083 3246083 3246083 3246083 3246083
12 Fan Assembly (includes motor, blade and guard) 3243804 3243804 3243804 3243805 3243805 3243805
3243805 3243805
13 Filter/Dryer - Liquid Line 3223812 3223812 3223812 3223812 3243615 3243615 3243616 3243616
14 Fuse - Control Board
1
5002943 5002943 5002943 5002943 5002943 5002943 5002943 5002943
15 Fuse - Control Transformer - Primary
1
3246089 3246089 3246089 3246089 3246089 3246089 3246089 3246089
16 Fuse - Control Transformer - Secondary
1
3246090 3246090 3246090 3246090 3246090 3246090 3246090 3246090
17 Fuse - Crankcase Heater
1
3246089 3246089 3246089 3246089 3246089 3246089 3246089 3246089
18 Heater, Crankcase 4010508 4010508 4010508 4010508 4010508 4010508 4010508 4010508
19 Motor Starter Protector - Compressor - Digital
1
5003506 5003506 5003506 5003506 5003506 5003506 5003506 5003506
20 Motor Starter Protector - Compressor - Fixed
1
5003506 5003506 5003506 5003506 5003506 5003506 5003506 5003506
21 Motor Starter Protector - Fan
1
3246077 3246077 3246077 3246078 3246078 3246078 3246078 3246079
22 Relay - High Pressure Cut-out
1
3246088 3246088 3246088 3246088 3246088 3246088 3246088 3246088
23 Sensor - Temperature
1
5007289 5007289 5007289 5007289 5007289 5007289 5007289 5007289
26 Switch
- Fan Cut-out #1 3230765 3230765 3230765 3230765 3230765 3230765 3230765 3230765
27 Switch - Fan Cut-out #2 N/A N/A N/A 3230766 3230766 3230766 3230766 3230766
28 Switch - High Pressure Cut-out 3230770 3230770 3230770 3230770 3230770 3230770 3230770 3230770
29 Switch - Low Pressure Cut-out 3230769 3230769 3230769 3230769 3230769 3230769 3230769 3230769
31 Transformer - Control
1
3246082 3246082 3246082 3246082 3246082 3246082 3246082 3246082
32 Valve - Automatic Drain (complete) 7428268 7428268 7428268 7428268 7428268 7428268 7428268 7428268
33 Valve - Solenoid - Digital Scroll 3232517 3232517 3232517 3232517 3232517 3232517 3232517 3232517
34
Valve - Solenoid Assembly - Digital Scroll
(includes solenoid valve and sound attenuation volumes)
3219039 3219039 3219039 3219039 3219039 3219039 3219039 3219039
35 Valve - Thermostatic Expansion (TXV) 3232550 3232550 3232550 3232550 3232532 3232532 3232533 3232533
230/3/60 Units Only
36 Main Transformer - 230/460
1
3230908 3230906 3230906 3230906 3230906 3230896 3230896 3230896
575/3/60 Units Only
37 Main Transformer - 575/460
1
3230907 3230907 3230907 3230895 3230895 3230908 3230908 3230908
1
Items 5, 6, 7, 8, 9, 10, 14, 15, 16, 17, 19, 20, 21, 22, 23, 31, 36, and 37 are located in the electrical enclosure located behind the control panel. Refer to the appropriate Electrical Schematic to identify part.
2
NOTE: Consult factory with the dryer serial number when ordering Item 10, Control Board.
REPLACEMENT PARTS: Air-Cooled Units
MAINTENANCE KITS
MODEL 800 1000 1250 1500 1750 2000 2500 3000
Moisture Separator Filter
(includes separator elements & drain rebuild kit)
HESMK27D2 HESMK27D2 HESMK27D2 HESMK27D2 HESMK28D2 HESMK28D2 HESMK28D2 HESMK28D2
Optional Oil Removal Filter
(includes separator elements, oil removal elements & drain rebuild kit)
HESMK47D2 HESMK47D2 HESMK47D2 HESMK47D2 HESMK48D2 HESMK48D2 HESMK48D2 HESMK48D2
Rebuild Kit - Automatic Drain 7428278 7428278 7428278 7428278 7428278 7428278 7428278 7428278
