SPECIFICATIONS
Level Sensor Input
(Digital Input)
• External switches can be attached to stop the pump and activate the
alarm (low reagent level) when the switch is open and level alarm is
configured in Setup
• Galvanic isolation
Power Supply 100 - 240 Vac, 50/60 Hz
Power Consumption 15 VA
Environment 0 to 50 °C (32 to 122 °F), max. 95% RH non-condensing
Dimensions 90 x 142 x 80 mm (3.5 x 5.6 x 1.8")
Weight 910 g (32 oz)
Casing Wall mounted, built-in pump, IP65 rated
4.3. pH & ORP PROBE SPECIFICATIONS
Specifications HI10053 (BL100) HI20083 (BL101)
Range 0 to 12 pH ±2000 mV
Reference Double junction Double junction
Junction Cloth Cloth
Temperature sensor Yes Yes
Temperature range -5 to 70 °C (23 to 158 °F) -5 to 70 °C (23 to 158 °F)
AmpHel
®
Yes Yes
Matching pin Yes Yes
Body PVDF (blue) PVDF (red)
Top thread " NPT " NPT
In-line mounting thread " NPT " NPT
Cable length 2 m 2 m
Connector Quick connect DIN connector Quick connect DIN connector
Maximum pressure @25 °C 3 bar (43.5 psi) 3 bar (43.5 psi)
