6160
Data transmission from the instrument to the PC can be done with the
HI 92000 Windows
®
compatible software (optional). HI 92000 also
offers graphing and on-line help feature.
Data can be exported to the most popular spreadsheet programs for
further analysis.
To connect your instrument to a PC, use an USB cable connector. Make
sure that your instrument is switched off and plug one connector to the
instrument USB socket and the other to the serial or USB port of your PC.
Note: If you are not using Hanna Instruments HI 92000 software,
please see the following instructions.
SENDING COMMANDS FROM PC
It is also possible to remotely control the instrument with any terminal
program. Use an USB cable to connect the instrument to a PC, start the
terminal program and set the communication options as follows: 8, N, 1,
no flow control.
COMMAND TYPES
To send a command to the instrument follow the next scheme:
<command prefix> <command
>
<CR>
where: <command prefix> is the 16 ASCII character
<command> is the command code.
Note: Either small or capital letters can be used.
SIMPLE COMMANDS
KF1 Is equivalent to pressing function key 1
KF2 Is equivalent to pressing function key 2
KF3 Is equivalent to pressing function key 3
RNG Is equivalent to pressing RANGE key
CAL Is equivalent to pressing CAL key
UPC Is equivalent to pressing the UP arrow key
DWC Is equivalent to pressing the DOWN arrow key
MNU Is equivalent to pressing MENU key
ESC Is equivalent to pressing ESC key
• Use the ARROW keys to set the calibration point value to that of the
hot water.
• When the reading is stable and close to the selected calibration
point, Confirm function key is displayed.
• Press Confirm to confirm. The instrument returns to the calibration
screen.
Note: Use ARROW keys to change calibration point if necessary
(±10.0 ºC) around the point.
If the reading is not close to the selected calibration point, “Wrong”
message will blink. Change the temperature probe and restart calibration.
PC INTERFACE
