7
FUNCTIONAL DESCRIPTION
FRONT PANELFRONT PANEL
FRONT PANELFRONT PANEL
FRONT PANEL
REAR PANELREAR PANEL
REAR PANELREAR PANEL
REAR PANEL
INSTRUMENT DESCRIPTION
1) Titrant bottle
2) Liquid Crystal Display (LCD)
3) Keypad
4) Electrode holder
5) Peristaltic pump tube
14
• Add the content of one powder packet of HI 84100-54
Stabilizer into the beaker.
• Place the probe holder on the top of the beaker and
secure it by turning clockwise.
• Immerse the ORP electrode approximately 2 cm
(0.8”) into the sample to be tested while paying
attention to not touch the stir bar.
• Insert the dosing tip in the appropriate holder place
and pay attention to not be immersed into solution.
• Press the START STOP button to start the titration.
The display will show “titr” during titration, along
with stirrer and pump tags blinking on the LCD.
• At the end of the titration, the Sulphur Dioxide
concentration is displayed in ppm (mg/L).
Note: If the equivalence point is not reached or it is not
recognized because of the noisy solution, an error
message will be displayed.
