6
SPECIFICATIONS HSPECIFICATIONS H
SPECIFICATIONS HSPECIFICATIONS H
SPECIFICATIONS H
II
II
I
9023C 9023C
9023C 9023C
9023C
& HI 9023CN& HI 9023CN
& HI 9023CN& HI 9023CN
& HI 9023CN
HI 9023C HI 9023CN
Range 0.00 to 14.00 pH
±399.9 mV (ISE); ±1999 mV (ORP)
0.0 to 100.0°C 0.0 to 70.0°C
Resolution 0.01 pH
0.1 mV (ISE); 1 mV (ORP)
0.1°C
Accuracy ±0.01 pH
(@20°C/68°F) ±0.2 mV (ISE); ±1 mV (ORP)
±0.4°C ±0.5°C
Typical EMC ±0.02 pH
Deviation ±0.2 mV; ±1 mV
±0.2°C ±0.5°C
Calibration Automatic with 3 memorized standard
buffers (4.01, 7.01, 10.01)
Temperature Automatic or manual Automatic
Compensation 0 to 100°C (32-212°F) 0 to 70°C (32-158°F)
Electrode HI1230B plastic body, HI1217D plastic body,
combination pH, BNC 4-in-1 gel pH/°C, DIN
1 m cable (included) 1 m cable (included)
Temperature Probe HI 7669/2W (incl.) not necessary
Input Impedance 10
12
Ohm
Battery Type & Life 4x1.5V, AA size (alkaline batteries)
approx. 400 hours of continuous use
auto-shut off after 10 minutes of non-use
Environment 0 to 50°C (32 to 122°F); 100% RH
Dimensions 196x80x60 mm (7.7x3.1x2.4") (meter)
340x230x80 mm (13.8x9x3.1") (kit)
Weight 425 g (15 oz.) (meter)
1.3 Kg (3.0 lb.) (kit)
35
120 mm
0.5"
FC 210
120 mm
0.5"
0.37"
FC 220
FC 210B
Glass-body, double junction, conic, Viscolene, non-refillable, combina-
tion pH electrode. Use: milk, yogurt.
FC 220B
Glass-body, triple-ceramic, single junction, refillable, combination pH
electrode. Use: food processing.
FC 911B
Plastic-body (Kynar
®
), double junction, refillable with built-in ampli-
fier, combination pH electrode. Use: very high humidity.
HI 1413B
Glass-body, single junction, flat tip, Viscolene, non-refillable, combi-
nation pH electrode. Use: surface measurement.
110 mm
12 mm
0.5"
FC 911
110 mm
0.5"
HI 1413
Kynar
®
is registered Trademark of "Pennwalt Corp."
Ultem
®
is registered Trademark of "General Electrics Co."
