User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 28” (27.5" viewable)
Pixel pitch 0.309mm(H) x 0.309mm(V)
H-Frequency 24KHz – 80KHz
Video
V-Frequency 56Hz– 75Hz
Display Colors 16.7M Colors
Maximum Screen Size
Hor. :593.28mm;
Ver. :370.8mm
Max. Resolution
WUXGA 1920 x 1200 @60Hz
Plug & Play
VESA DDC2B
TM
ON Mode
≤64.5W
Power Saving Mode
≤2W
EPA ENERGY
STAR
®
OFF Mode
≤1W
Input Terminal
D-Sub
HDMI (support DVI-D signal)
Output Terminal
Speakers 2.5W x 2
Power Source
100 ~ 240 VAC ±10%, 50± 3Hz ,60± 3Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Dimensions
668(W)×486(H)×211(D) mm
26.3”(W)×19.1”(H)×8.3”(D)
Weight (NW)
10.8 kg
23.8 lb
***The above specification is subject to actual product specification and is subject to
change without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can
refer to
www.hannsg.com FAQ section.
20
