Hantek HDG 2000 Series - Front-Panel Menu Reference

Basic Operation
HDG2000 Series Arbitrary Waveform Generator 13
2.1 Front-Panel Menu Reference
Overview of the front-panel menus. The remainder of this chapter contains examples of using the
front-panel menus.
Configures waveform-specific parameters
 Period/Frequency
 Amplitude or High and Low Voltage
 Offset
 Phase
 Duty Cycle
 Symmetry
 Pulse Width
 Edge Time
 Arbitrary Waveform
 Bandwidth
Sine
Square
Ramp
Pulse
Noise
Arb
Harmonic
CH1and CH2 switch button
Frequency/Time hot key
Amplitude hot key
Offset hot key
