Hantek HDG 2000 Series - Function Subsystem

SCPI Programming Reference
HDG2000 Series Arbitrary Waveform Generator 77
FSK rate should be used only with the internal modulation source(FSK:SOURce INTernal).
5.2.12 FUNCtion Subsystem
The FUNCtion subsystem configures the instrument's output function:
SOURce<n>:FUNCtion <wave>
output waveform
SOURce<n>:FUNCtion:ARBitrary <filename>
Output arbitrary waveform file
SOURce<1|2>:FUNCtion:ARBitrary:PTPeak
peak-to-peak voltage for an arbitrary waveform
SOURce<1|2>:FUNCtion:ARBitrary:SRATe
sample rate for arbitrary waveform
SOURce<n>:FUNCtion:SQUare:DCYCle
pulse duty cycle for pulse
SOURce<n>:FUNCtion:RAMP:SYMMetry
symmetry percentage for ramp
SOURce<n>:FUNCtion:PULSe:DCYCle
pulse duty cycle for pulse
SOURce<n>:FUNCtion:PULSe:WIDTh
pulse width
SOURce<n>:FUNCtion:PULSe:TRANsition:LEADing
Leading edge time for pulse
SOURce<n>:FUNCtion:PULSe:TRANsition:TRAiling
Trailing edge time for pulse
SOURce<n>:FUNCtion <wave>
SOURce<n>:FUNCtion?
Selects output function
Parameter
Typical Return
SINusoid|SQUare|RAMP|
PULSe|NOISe|DC|SINC|EXPFall|HAVErsine
|LOREntz| DUALtone|GAUSe|
ECG| USER| HARMonic|, default SINusoid
SINusoid, SQUare, RAMP, PULSe, NOISe, DC,
SINC, EXPFall、HAVErsine, LOREntz,
DUALtone, GAUSe, ECG, USER, or HARMonic|
Set output on channel 1 to sine: SOURce1:FUNCtion SINusoid
NOISe generates white gaussian noise
ARB generates the arbitrary waveform currently selected by FUNCtion:ARBitrary.
SOURce<n>:FUNCtion:ARBitrary <filename>, SOURce<n>:FUNCtion:ARBitrary?
