Hantek HDG 2000 Series - Fskey Subsystem

SCPI Programming Reference
HDG2000 Series Arbitrary Waveform Generator 76
Sets the output frequency
Parameter
Typical Return
Different waveform has diffenent frequency
range, please refer to Output Configuration
and Appendix B
+1.000000000000000E+03
Set output frequency to 100 Hz: SOURce1:FREQuency 100
SOURce<n>:FREQuency:CENTer <frequency>|MINimum|MAXimum
SOURce<n>:FREQuency:CENTer? [MINimum|MAXimum]
Sets the center frequency. Used with frequency span for a frequency sweep.
Parameter
Typical Return
Different waveform has diffenent frequency
range, please refer to Output Configuration
and Appendix B
Default 550Hz
+1.000000000000000E+03
Set sweep center frequency to 1 kHz: SOURce1:FREQuency:CENTer 1000
The following equation shows how span relates to start and stop frequencies.
Frequency Span = Stop Frequency + Start Frequency
The following equation shows how center frequency relates to start and stop frequencies.
Center Frequency = (|Stop Frequency + Start Frequency|)/2
5.2.11 FSKey Subsystem
FSKey subsystem sets the FSK waveform.
SOURce<n>:MOD:FSKey:FREQuency <frequency>|MINimum|MAXimum
SOURce<n>:MOD:FSKey:FREQuency? [MINimum|MAXimum]
Set the FSK alternating frequency (or "hopping").
Parameter
Typical Return
please refer to Output Configuration and
Appendix B Default 100Hz
+2.000000000000000E+02
Set “hopping” rate to 200Hz on CH1: SOURce1:MOD:FSKey:FREQuency 200
SOURce<n>:MOD:FSKey:INTernal:RATE <frequency>|MINimum|MAXimum
SOURce<n>:MOD:FSKey:INTernal:RATE? [MINimum|MAXimum]
Set the ‘moving’ rate of output frequency between carrier frequency and hopping frequency.
Parameter
Typical Return
2 mHz to 1 MHz, default 100Hz
+2.000000000000000E+02
Set moding rate to 200Hz on CH1: SOURce1:MOD:FSKey:INTernal:RATE 200
