Pulse width
>100ns
Trigger Output
Level TTL - compatible
Pulse Width >60ns
Maximum
Rate
1MHz
Clock Reference
External Reference Input
Lock Range
10 MHz + 50 Hz
Level Low level: 0~400mV, high level: 2.5V~ 5V
Locking Time <2s
Impedance 50Ω, DC coupling
Internal Reference Output
Frequency
10 MHz + 50 Hz
Level
3.3 Vpp
Impedance
(typical)
50Ω, DC coupling
Sync Output
Level TTL - compatible
Impedance 50Ω, nominal value
CH3 Output (HDG3000C series only)
Standard
Waveforms
Sine, Square, Ramp, Noise, Harmonic, DC
Arbitrary
Waveforms
More than 160 kinds, including Sinc, Exponential Rise, Exponential Fall,
ECG, Gauss, Haver Sine, Lorentz, Dual
-Tone, etc.
Frequency
Sine: 1uHz ~ 20MHz
Square: 1uHz ~ 5MHz
Ramp: 1uHz ~ 1MHz
Harmonic: 1uHz ~ 15MHz
Arb: 1uHz ~ 5MHz
Frequency
Accuracy
±1ppm, 18~28℃
Sampling rate 150MSa/s
Waveform
Length
8K
Vertical
Resolution
12bit
Amplitude 2mVpp ~ 7Vpp (HighZ)
