Quick start
EN
HDP10000 series user manual Copyright Qingdao Hantek Electronics Co., LTD
12
Press the to enable the OCP function. The indicator light will be on. Press
again to disable the OCP function, the indicator will be off. Long press to enter
the setting mode, use the current value adjustment knob to change the OCP set value.
When the actual output current value is higher than the OCP set value, the protection
function will be triggered and the screen will display . The output is forcibly turned
off, but the ON/OFF indicator light is not turned OFF. Press to clear the error and
turn off the indicator light.
11. Voltage value adjustment knob
It is the same as the current value adjustment knob.
12.
Press the to enable OVP function. The indicator light will be on. Press
again to disable OVP function. The indicator light will be off. Long press to enter
the setting mode and use the voltage adjustment knob to change the OVP set value.
When the actual output voltage value is higher than the OVP set value, the protection
function will be triggered and will be displayed on the screen. The output is
forcibly turned off, but the ON/OFF indicator light is not turned off. Press to clear
the errors and turn off the indicator light.
13. CC constant current output state
Under constant current working state, the status indicator will be on.
14. Button lock
Press . The indicator light will be on. In button lock mode, only and
can be used. Press the again to quit this mode.
15. CV constant voltage output state
Under constant voltage working state, the status indicator will be on.
