Hantek HDP135V6 User Manual

Performance indicators
EN
Copyright Qingdao Hantek Electronics Co., LTD HDP10000 series user manual
15
6 Performance indicators
Rated operating condition
Working conditions: temperature -10℃~40℃, relative humidity ≤80%
Storage conditions: temperature -20℃~60℃, relative humidity ≤80%
Ac input: 115 VAC ± 10%, 230 VAC ± 10%, 50/60Hz
Indicators
All technical indicators can only be guaranteed when the instrument is operated
continuously for more than 30 minutes under the specified operating temperature (18℃
to 28℃).
Voltage
Load regulation
≤0.1% + 5mV
Linear regulation
≤0.01% + 5mV
Setting resolution
HDP135V6S
10mV
HDP180V8S
10mV
HDP1160V4S
0~100V
10mV
100~160V
100mV
Setting precision
≤0.1% + 1 digits
Read back resolution
HDP135V6S
10mV
HDP180V8S
10mV
HDP1160V4S
0~100V
10mV
100~160V
100mV
Read back accuracy
≤0.1% + 1 digits
Ripple
HDP135V6S
10mVrms
HDP180V8S
10mVrms
HDP1160V4S
15mVrms
Overvoltage
protection(OVP)
HDP135V6S
0 ~ 37V ± 0.2%FS
HDP180V8S
0 ~ 88V ± 0.2%FS
HDP1160V4S
0 ~ 176V ± 0.2%FS
Maximum voltage
HDP135V6S
35.2V ± 0.2%
HDP180V8S
81V± 0.2%
HDP1160V4S
162V± 0.2%
Current
Load regulation
≤0.2% + 3mA
Linear regulation
≤0.2% + 3mA
Setting resolution
1mA
Setting precision
≤0.2% + 3mA
Read back resolution
1mA
Read back accuracy
≤0.2% + 3 digits
Ripple
HDP135V6S
5mArms
HDP180V8S
8mArms
HDP1160V4S
10mArms
