Page #3 background imageLoading...
Page #3 background image
5
ORDERING INFORMATION
6
INSTRUCTION
2
3
RT9
0 : Recorder
1 : Recorder & Temperature Controller
0 : ℃ exclusive use
1 : Others
0 : None
1 : Alarm 1
2 : Alarm 1,2
3 : RS485
4 : RS485/Alarm 1
5 : RS485/Alarm 1,Alarm 2
제어출력구성
0
1
2
3
RT9 - 1󱅜 󱅜
Relay (ON/OFFcontrol)
SSR
SCR (4~20mADC)
Relay (P.I.Dcontro)
Installation
For NX9, 7, 3 and 2, attach the brackets (2 units) on the fixed halls and tighten with a
screwdriver.
Fixing torque is about 14.7N. cm (1.5kg.cm). NX1 and NX4 has a plastic bracket.
(Care should be taken not to tighten forcedly.)
Caution on terminal connections
Use a compensating cable with thermocouple.
For R.T.D input use a cable which is
a small lead wire resistance and without resistance
difference to 3wires.
To avoid inductive noise to input wires seperate from the power and output wires.
Keep input wires away from output wires and use shielded wires to earth.
If the wiring has noise, use the following step: connect a surge absorber to the conductor
coil side if the conductors are connected to the load output, such as the relay contact output.
Use an insulating transformer with a noise filter when the power suppy has much noise.
Noise filter should be mounted on a panel which has been earthed and the wiring between
the noise filter output and the instrument power terminals should be shorten.
It is effective to use a twisted cable for power supply against noise.
The heater power supply and the instrument power supply should be connected using the
same power suppy when a heater break alarm.
Time for preparation of contact output is required at power ON. When the output signal is
used for an extenal interlock circuit, connect a delay relay.
For load circuit connection
Use an extra relay when the frequency of operation is rather high. In thic case,
SSR output type is Recommended.
Electromagnetic switch : Proportional cycle time is Min. 30sec
SSR : Proportional cycle time is Min. 1 sec
Contact output life : Mechanical : Min. 10 million times (no load)
Electrical : Min. 100 thousand times (rated load)
SSR drive pulse voltage, DC 4~20mA are not insulated with internal circuit.
Use non-grounded sensor to R.T.D and thermocouple.
For waterproof (Waterproof type)
The instrument has IP65. Use rubber packing when installing the instrument to panel.
Please attach the rubber in correct way.
Caution on key operation / trouble
If alarm function is not set correctly, alarm output can not be operated at a trouble.
Be sure to check the alarm operation.
If the input cable is disconnected, the display shows .
When replacing the sensor, please turn OFF the power supply.
Other
Do not use organic solvents such as alcohol, benzine when cleaning. (Use neutral detergent)
This instrument has process-value (PV) and set-value (SV) each 4 digits with 7 segment FND. This
instrument is divided Recorder and Recorder with Controller.
Function and feature : Group P.I.D, Universal-input (19 types), Universal-output (Relay, SSR, 4~20mA),
Auto-tuning 2 types (standard type, low PV type), Communication (RS485),21 types of alarm,
Sampling cycle 250ms, ±0.3 of FS high accuracy. And there are Zoom function, Graphic or Text
printing selectable function, List function, Feed function, Free scale function. RTP is the smallest
Recorder with controller.
Recorder &
Temperature Controller
Control Output
Output code
