7 8
SPECIFICATION
4
1)
I N P U T
I n p u t
Sampling time
Input resolution
Input impedance
Lead wire tolerable
r e s i s t a n c e
I n p u t
tolerable voltage
Noise removal rate
S t a n d a r d
Standard junction temp.
compensation tolerance
B u r n - o u t
A c c u r a c y
Input range
Thermocouple: K, J, E, T, R, S, B, L, N, U, WRe 5-26, PL-Ⅱ
R.T.D: Pt 100Ω, KPt 100Ω
Direct voltage: 1~5V, -10~20mV, 0~100mV(Programmable scale type)
2 5 0 m S
Below decimal point of measurement range
T/C and mV input: 1MΩ min., DC V: 1MΩ
R.T.D: 10Ωmax. / wire
±10V (T/C, R.T.D, Voltage: mV DC)
±20V (Voltage: V DC)
NMRR(normal mode): 40dB min.
CMRR(common mode): 120dB min. (50/60Hz ±1 % )
T/C, R.T.D: KS, IEC, DIN
±1 . 5℃( 1 5 ~ 3 5℃), ±2 . 0℃( 0 ~ 5 0℃)
T/C: OFF, Up/Down selectable
R.T.D: Up scale (Detection current: 50mA)
±0.3% (Full scale)
Refer to “Input signal and Measurement range”
T/C and R.T.D are changeable within range of input signal and measurement range.
Voltage: min. voltage and max. voltage are available within range of measurement.
Scaling available.
2)
O U T P U T
R e l a y
contact output
Contact capacity: 240VAC 1A, 30V DC 1A(resistive load)
Contact: 1a
Output points: 2 Points (AL1,AL2)
① ALARM (H B A O U T P UT)
② CONTROL OUTPUT
Relay
contact output
SSR drive
voltage output
Current output
Contact capacity: 240VAC 3A, 30VDC 3A (resistive load)
Contact: 1C
Output operation: P.I.D control, ON/OFF
Proportional cycle: 1~1,000 sec.
Output limit: 0.0~100.0% range, higher limit(OH) or lower limit(OL)
selectable (valid when AT)
ON/OFF hysteresis: 0~100%(Full scale)
Time resolution: 0.1% or 10mS
ON voltage:24VDC min.(resistive load 600Ω min., 30mA limit when short)
OFF voltage: 0.1VDC max.
Proportional cycle: 1~1,000 sec.
Output operation: P.I.D control
Output limit: 0.0~100.0% range, higher limit(OH) or lower limit(OL)
selectable (valid when AT)
Time resolution: 0.1% or 10mS
Current output range: 4~20mA DC
Resistive load: 600Ω m a x .
Accuracy: ±0.5% of full scale (4~20mA range), Resolution: Approx. 3,000
Output ripple: 0.3%(P-P) of max. scale (150Hz)
Sampling time: 250mS
Output operation: P.I.D control
Output limit: -5.0~105.0% range, higher limit(OH) or lower limit(OL)
selectable (valid when AT)
Input correction (Bias): -100.0~100.0% for instrument range
Scaling : According to SH, SL of measurement range
Filter : OFF, 1~120 sec.
3 settings (SV1, SV2 and SV3) and P.I.D setting each
Auto tuning : According to set value (Standard type, Low PV type)
Proportional Band : 0.1~999.9% (Max. range)
Integral Time : OFF, 1~6000 sec.
Derivative Time : OFF, 1~6000 sec.
ON/OFF control: By selecting output code (OT) “ 0 ”
P.I.D selection : Zone PID/Auto 1,2,3, selectable
Manual Reset : -5.0~105.0% of output (valid when I=OFF)
Direct / Reverse action : Changeable by parameter
Preset output limit : -5.0~105.0% of output value
ON/OFF hysteresis (HYS): 0.0~100.0% of instrument range (valid when ON/OFF control)
A.R.W(Anti Reset Wind-up): AUTO, 50.0~200.0%
Fuzzy : selection ON/OFF by parameter
Ramp function
Set point : 2 Points
Multi-alarm : High/Low process alarm, High/Low deviation alarm, Hold function of alarm,
Heater break alarm (H.B.A)
Setting range : Process alarm ⋯⋯ 0~100% of instrument range
Deviation alarm ⋯⋯ -100~100% of instrument range
Measuring point : 1
Response time : According to chart speed
Record type : Thermal line
3)
F U N C T I O N
Measurement input
Control
Alarm output
Record
Storage temperature
Storage humidity
Shock
Installation environment
Normal operation
condition
Influence of ambient
temperature
Continuous vibration (5~14Hz): Forward width 1.2mm max.
(4~150Hz): 4.9㎨ (0.5G) max.
Vibration : 14.7㎨ (1.5G), 15 sec. max. (each 3 direction)
Shock : 147㎨ (15G), 11msec max. (6 direction each 3 times)
Panel cutout: Page 11, 12
Ambient temperature : 0~50℃
Ambient humidity : 20~90%RH (no condensation)
Influence of magnetic : 400AT/m max.
Warm-up time: 30 min. min.
T/C, Voltage input : ±1μV/℃ or ±0.01%/℃ of max. range
R.T.D input : ±0.05Ω/℃ max.
Analog output : ±0.05%/℃ max. (continuous output)
4)
OPERATING ENVIRONMENT
5)
STORAGE CONDITION
-25~70℃
5~95%RH (no condensation)
1m max. in packing condition
