11
FINAL INSTALLATION
Switch
Housing
Plate
Pull Chain Slot
Fig. 5
A
E
6. Remove socket ring (L) from each socket. Use
one socket ring (L) to attach each glass shade
(F). (Fig. 6)
Note: Do not overtighten socket rings (L) as
glass may crack or break
.
7. Install four candelabra base 60 watt max.
bulbs (I) included. (Fig. 7)
Important: When you need to replace bulbs,
please allow bulbs and glass shades (F) to cool
down before handling them.
5. Gently push wires and molex connections into switch
housing plate. Align fan pull chain slot with fan pull
chain and attach light kit fitter (B) to fan with screws that
were removed in the previous step. Use a Phillips
screwdriver to secure all three screws. (Fig. 5)
Fig. 6
F
F
L
Fig. 7
I
Fig. 7
I
