HARDWARE CONTENTS
Part Description Quantity Part Shown to Size
Motor Screw (10 in motor; 1 in hardware pack) 11
3/16 Blade Screw (in hardware pack) 16
5.4M/M Lock Washer (10 in motor; 11
1 in hardware pack)
Blade Washer (in hardware pack) 16
E3 Wire Connector (in hardware pack) 4
Motor Housing Mounting Screw
(attached to mounting bracket)
AA
5
BB
CC
DD
EE
1. Before beginning assembly, installation or operation of product, make sure all parts are
present. Compare parts with package contents list and diagram above. If any part is missing or
damaged, do not attempt to assemble, install or operate the product.
Estimated Assembly Time: 120 minutes
Tools Required for Assembly (not included): electrical tape, Phillips screwdriver, pliers, safety
glasses, stepladder, wire strippers.
Helpful Tools (not included): A/C tester light, tape measure, do-it-yourself wiring handbook
(available at Lowe’s), wire cutters.
PREPARATION
FF
4
To Next Page
