Purchase Date

4007498

ITEM #5127844

COGDELL CEILING FAN

Español p. 20

MODEL #COG60BNK7LR

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could

also contact us at partsplus@lowes.com.

SS22004

ATTACH YOUR RECEIPT HERE

ADJUNTE SU RECIBO AQUÍ

HARBOR BREEZE and logo design are

trademarks or registered trademarks of

APPROVED FOR USE IN

DAMP LOCATIONS

Main Page

Questions and Answers

A
Andres ClarkAug 6, 2025
Why is my Harbor Breeze Fan making noise?
- M
  Mrs. Ellen HoustonAug 6, 2025
  There are several reasons for a noisy Harbor Breeze Fan. First, check if the blades are loose and tighten all blade screws. A cracked blade can also cause noise, so replace the blade if necessary. If the fan is new, allow it a 'break-in' period of a few days, especially when running it at medium and high speeds.
P
Pamela HarrisAug 18, 2025
What to do if my Harbor Breeze Fan does not move?
- E
  Elaine FordAug 19, 2025
  If your Harbor Breeze Fan isn't moving, start by checking if the power is on or if a fuse is blown; if so, turn the power on or check the fuse. Also, a faulty wire connection could be the cause, so turn the power off, loosen the canopy, and check all connections. Ensure that the molex connections in the LED light kit are properly connected. Finally, make sure all blades are installed.

Summary

Safety Information

FCC Compliance Notice

Details FCC compliance for the remote control and LED light kit.

Safety Information

Critical Installation Warnings

Covers DANGER and WARNING notices for installation risks.

Safety Information

General Safety Advice

Includes warnings on blade handling and cautions for installation.

Initial Installation

Mounting Method Selection

Guidance on choosing between downrod and closemount installation methods.

Final Installation

Blade Attachment

Instructions for attaching fan blades to the motor housing.

Fitter Plate Installation

Steps for installing the fitter plate to connect the light kit.

Final Installation

LED Light Kit and Shade Installation

Guidance for connecting the LED light kit and attaching the shade.

Final Installation

Remote Control Bracket Mounting

Instructions for mounting the remote control bracket on walls.

Operating Instructions

Remote Control Functions

Explanation of buttons and features on the remote control transmitter.

This document describes the Harbor Breeze Cogdell Ceiling Fan (Model #COG60BNK7LR), an indoor ceiling fan with an integrated LED light kit and remote control.

Function Description:

The Cogdell Ceiling Fan is designed to provide air circulation and illumination in residential spaces. It features a DC motor for quiet operation and offers both downrod-style (standard or angled ceiling) and closemount-style (standard ceiling only) installation options. The fan comes with a remote control for convenient operation, allowing users to adjust fan speed, light settings, and access special modes like Breeze mode and Vacation mode. The LED light kit provides adjustable color temperature and dimming capabilities.

Important Technical Specifications:

Item Number: #5127844
Net Weight (including light kit): 15.65 lbs
Fan Support: Mount to an outlet box marked "ACCEPTABLE FOR FAN SUPPORT OF 35 LBS. (15.9 KG) OR LESS"
Minimum Clearance (Blades to Floor): 7 ft
Minimum Clearance (Blades to Obstruction): 30 in from the end of the blades
Ceiling Angle (for angled mount): Not steeper than 15° (or 19° for mounting bracket installation)
Electrical Rating (Remote Control): 120V / 60 Hz
Motor Amps (Remote Control): 1.25 MAX
Total Wattage (Fan): 20 watts (LEDs are not replaceable)
Light Kit: Integrated LED, dimmable to 10%
Remote Control Batteries: 2 x AAA (not rechargeable)
FCC Compliance: Class B digital device, Part 15 of FCC Rules. Operation is subject to two conditions: (1) device may not cause harmful interference, and (2) device must accept any interference received.
Safety Certifications: ETL Listed (Intertek 4007498), Approved for use in damp locations.

Usage Features:

Installation Options:
- Downrod Mount: Suitable for ceilings 8 ft or higher, or angled/vaulted ceilings (up to 15°/19° angle). A longer downrod (not included) may be needed for taller or angled ceilings to ensure proper blade clearance.
- Closemount Mount: Suitable for standard ceilings only.
Remote Control Operation:
- Fan Speeds: 6 adjustable speeds (1 lowest, 6 highest).
- Reverse Function: Allows changing blade direction (fan must be on low speed before reversing).
- Timer Function: Set fan to run for 1 hour, 4 hours, or 8 hours.
- Light Control: ON/OFF, dimming, and color mode selection.
- Color Modes: Warm white, bright warm white, natural white, bright white, daylight.
- Dimming: Hold the light button to increase or decrease light. Holding for more than 7 seconds activates a cyclical dimmer (8-second cycle).
- Auto Resume Function: The light and fan will resume at the last brightness/speed setting when turned off and on.
- Breeze Mode: Fan automatically cycles through all 6 different speeds.
- Vacation Mode: Light kit switches on for 5 minutes every 2 hours.
Remote Control Pairing: If the fan or remote fails to operate, or if a new remote is purchased, the remote can be paired by turning off the power, restoring it, and within 30 seconds, pressing and holding the ON/OFF button (for fan) on the remote for 5 seconds until the fan beeps.
Safety Warnings:
- Do NOT use power tools for assembly, especially for blades, to prevent injury or damage.
- Ensure the outlet box is securely attached to the building structure and can support the fan's weight (at least 35 lbs). Use a METAL octagonal outlet box, not plastic.
- Do not bend blades during installation, balancing, or cleaning.
- Do not insert objects between rotating fan blades.
- Use ONLY parts provided with the fan to avoid voiding the warranty.
- Shut off electricity at the main switch or circuit breaker before installation or maintenance.
- Ensure the outlet box is properly grounded.
- Do not tamper with or attempt to repair the LED component; service by untrained personnel is not recommended.
- The DC motor will not operate until blades are installed.
- Do not use with any solid-state speed control device or full-range dimmer switch, as this can cause humming noise, fire, or electrical shock.
- Wire connectors are designed for one 12-gauge house wire and two fan lead wires. Consult an electrician if house wire is larger or if there are more wires.
- Batteries must be inserted with correct polarity. Do not mix battery types (alkaline, carbon-zinc, rechargeable) or old and new batteries. Dispose of batteries properly.

Maintenance Features:

Regular Checks: At least twice a year, lower the canopy to check the downrod assembly and tighten all screws on the fan.
Cleaning:
- Clean the motor housing with a soft brush or lint-free cloth to avoid scratching the finish.
- Clean blades with a lint-free cloth.
- A light coat of furniture polish can be applied to wood blades for added protection.
Important Cleaning Note: Shut off the main power supply before any maintenance. Do NOT use water or a damp cloth to clean the ceiling fan.
LEDs: The integrated LEDs are not designed to be replaced by the user.
Troubleshooting Guide: The manual provides a comprehensive troubleshooting section for common issues such as the fan not moving, noisy operation, excessive wobbling, light failure, and remote control malfunction, along with possible causes and corrective actions.
Warranty: Limited Lifetime Warranty covering defects in workmanship and materials from the date of purchase for the original purchaser. Replacement of defective parts within the first year. For warranty service, present a sales receipt. The warranty does not cover damage from accident, misuse, improper installation, or use of non-manufacturer parts. It also does not cover changes in brass finish due to climatic conditions or glass parts.
Customer Service: For questions, problems, missing parts, or replacement parts, contact the customer service department at 888-251-1003 (8 a.m. - 8 p.m., EST, Monday - Sunday) or email partsplus@lowes.com.
