Harbor Freight Tools TITANIUM TIG200 - Reference Information; Parts List and Diagrams

Page 28 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 56825
?@<6AQ D@CEA6E@ER6S@?CR%T6GUCEV T6GUCEV%ACW?SETUP
W,($#%G"#$%,89%U",3(,5#
W,($#%G"#$
W,($ U*#4("/$"&8 i$>
1 Handle 1
2 Top Housing 1
3 Main PCB 1
4 Control PCB 1
5 IGBT Radiator-Front 2
6 Cassette Holder 1
7 Arc PCB 1
8 Air Isolation Plate 2
9 IGBT 16
10 Front PCB 1
11 Bracket 1
12 Control Panel 1
13 TIG Torch 1
14 Electrode Holder 1
15 Knob 1
16 Negative Socket 1
17 Pneumatic Connector 1
W,($ U*#4("/$"&8 i$>
18 Copper Anode 1
19 Foot Pedal Socket 1
20 Positive Socket 1
21 Switch 1
22 Copper Cathode 1
23 Ground Clamp 1
24 Front Panel 1
25 Pet 1
26 Foot Pedal 1
27 Arc Inductance 1
28 Current Sensor 1
29 Transformer 1
30 Inductance 1
31 Inverter Radiator 1
32 High Recovery Rectifier 6
33 High Recovery Tube 4
34 Rectifier Radiator 2
W,($ U*#4("/$"&8 i$>
35 Output PCB 1
36 Bearing 1
37 Bottom Housing 1
38 Fan 1
39 ௘93OXJ$GDSWHU 1
40 Cable Clip 1
41 Power Cord 1
42 Rear Panel 1
43 Valve Interface 1
44 Fixture 1
45 Solenoid Valve 1
46 Tube Connector 1
47 IGBT 8
48 IGBT Radiator-Rear 2
49 Bridge Heat Sink 1
50 Bridge Rectifier 2
