Hardi HC5500 Installation Manual

3
020-056-UK
HARDI HC5500 w/ JobCom
INTRODUCTION TO MATRIX  BOOMPILOT
Principle of Operation
The Matrix controls the sprayer according to the GPS position as well as the GPS
guidance to avoid overlaps or skips.
The Matrix controls the sprayer in automatic mode and monitor the sprayer in manual
mode. The operator is always able to override the control of the sprayer via the master
switch on the HARDI SPRAYER II switch box..
HARDI HC5500 W/ JOBCOM
Features
The Matrix in combination with the Hardi smartcable for HC5500 w/jobCom, adds
'Automatic Boom Section Control' to the sprayer.
Software version
The HARDI HC5500 and the MATRIX communicates via a special RS232 to CAN device.
Therefore the software version in the HARDI HC5500 must be v4.16 or higher.

Hardi HC5500 Specifications

General

Brand	Hardi
Model	HC5500
Category	Controller
Language	English
