3 - Description
28
Hydraulic Systems
Hydraulic Blocks
Hydraulic blocks fitted to the sprayer are:
Boom
The main boom hydraulic block that manages hydraulic pressure for the
boom controls.
ParaLift
This hydraulic block manages hydraulic pressure for the ParaLift.
Open Centre Hydraulics
The open centre hydraulic block is necessary if the tractor uses open
centre hydraulics and/or load sensing. For adjustment, see “Open Centre
Hydraulics (optional)” on page 39.
