Harman Kardon AVR 130

14/14
Pos Part number 1st part name 2nd part name
L704 KLZ9H001Z BEAD , CORE
L705 KLZ9H001Z BEAD , CORE
R781 CRG2ANJ150H RES , METAL OXIDE FILM 15 OHM 2W J
R782 CRG2ANJ330H RES , METAL OXIDE FILM 33 OHM 2W J
X701 HOX12288E220TF CRYSTAL(HC-49/S,ATS) 12.288MHZ 22PF
1/3
Pos Part number 1st part name 2nd part name
COP11581E VIDEO PCB ASS'Y
C404 CCKT1H101KB CAP , CERAMIC 100PF 50V KB
C407 CCKT1H101KB CAP , CERAMIC 100PF 50V KB
C411 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C412 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C413 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C414 HCBS1H151KBT CAP , CERAMIC 150PF 50V K
C416 HCEA1CH101T CAP , ELECT 100UF 16V
C417 HCEA1CH101T CAP , ELECT 100UF 16V
C418 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C420 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C421 HCEA1CH101T CAP , ELECT 100UF 16V
C422 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C423 HCEA1CH101T CAP , ELECT 100UF 16V
C427 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C428 HCEA1CH101T CAP , ELECT 100UF 16V
C429 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C430 HCEA1CH101T CAP , ELECT 100UF 16V
C436 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C437 HCEA1CH101T CAP , ELECT 100UF 16V
C438 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z
C439 HCEA1CH101T CAP , ELECT 100UF 16V
C461 HCEA1CH101T CAP , ELECT 100UF 16V
C462 HCEA1CH101T CAP , ELECT 100UF 16V
C463 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z
C498 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C499 HCBS1H101KBT CAP , CERAMIC 100PF 50V K
C701 HCEA1AH471T CAP , ELECT 470UF 10V
C702 HCEA1AH471T CAP , ELECT 470UF 10V
C703 CCKT1H181KB CAP , CERAMIC 180PF 50V KB
C704 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF
C705 CCKT1H181KB CAP , CERAMIC 180PF 50V KB
C706 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF
AVR130 INPUT
AVR130 VIDEO
