INPUT PCB ASSY
Ref. # Part Number
Description
V
alue
C631 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C704 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C707 CCUS1H102KC CAP , CHIP 1000PF 50V K
C719 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C738 CCUS1A105KC CAP , CHIP 1UF 10V K
C739 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C743 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C757 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C759 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C760 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C761 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C762 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C763 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C769 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C770 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C771 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C772 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C773 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C793 CCUS1H101JA CAP , CHIP 100PF 50V J
C799 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C800 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C804 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C808 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C809 CCUS1H104KC CAP , CHIP 0.1UF 50V K
D201 CVD1SS355T DIODE , CHIP
D202 CVD1SS355T DIODE , CHIP
D203 CVD1SS355T DIODE , CHIP
D204 CVD1SS355T DIODE , CHIP
D207 CVD1SS355T DIODE , CHIP
D208 CVD1SS355T DIODE , CHIP
D209 CVD1SS355T DIODE , CHIP
D210 CVD1SS355T DIODE , CHIP
D211 CVD1SS355T DIODE , CHIP
D212 CVD1SS355T DIODE , CHIP
D213 CVD1SS355T DIODE , CHIP
D214 CVD1SS355T DIODE , CHIP
D228 CVD1SS355T DIODE , CHIP
D229 CVD1SS355T DIODE , CHIP
IC77 HVI57V161610ET7 SDRAM 16M 7NS HY57V161610ET-7
R254 CRJ10DJ4R7T RES , CHIP 1608 SIZE
R255 CRJ10DJ4R7T RES , CHIP 1608 SIZE
R256 CRJ10DJ4R7T RES , CHIP 1608 SIZE
R257 CRJ10DJ4R7T RES , CHIP 1608 SIZE
R259 CCUS1H104KC CAP , CHIP 0.1UF 50V K
R260 CRJ10DJ0R0T RES , CHIP 1608 SIZE
R723 CRJ10DJ2R7T RES , CHIP 1/10W 2.7
R727 CRJ10DJ473T RES , CHIP 1608 SIZE
R729 CRJ10DJ123T RES , CHIP 1608 SIZE
R730 CRJ10DJ123T RES , CHIP 1608 SIZE
R739 CRJ10DJ1R0T RES , CHIP 1608 SIZE
R740 CRJ10DJ820T RES , CHIP 1608 SIZE
CIP12187BTSMD AVR139/230 INPUT PCB TOP SMD ASS'Y
CUP12187Z AVR139/230 PCB , INPUT (FR-4,216X168)
C201 CCUS1H221JA CAP , CHIP 220PF 50V J
C202 CCUS1H221JA CAP , CHIP 220PF 50V J
C203 CCUS1H221JA CAP , CHIP 220PF 50V J
C204 CCUS1H221JA CAP , CHIP 220PF 50V J
C205 CCUS1H221JA CAP , CHIP 220PF 50V J
C206 CCUS1H221JA CAP , CHIP 220PF 50V J
C209 CCUS1H221JA CAP , CHIP 220PF 50V J
C210 CCUS1H221JA CAP , CHIP 220PF 50V J
C211 CCUS1H221JA CAP , CHIP 220PF 50V J
C212 CCUS1H221JA CAP , CHIP 220PF 50V J
C213 CCUS1H221JA CAP , CHIP 220PF 50V J
C214 CCUS1H221JA CAP , CHIP 220PF 50V J
C215 CCUS1H221JA CAP , CHIP 220PF 50V J
C216 CCUS1H221JA CAP , CHIP 220PF 50V J
C219 CCUS1H221JA CAP , CHIP 220PF 50V J
C220 CCUS1H221JA CAP , CHIP 220PF 50V J
C221 CCUS1H221JA CAP , CHIP 220PF 50V J
C222 CCUS1H221JA CAP , CHIP 220PF 50V J
C223 CCUS1H221JA CAP , CHIP 220PF 50V J
C224 CCUS1H221JA CAP , CHIP 220PF 50V J
C269 CCUS1A105KC CAP , CHIP 1UF 10V K
C274 CCUS1A105KC CAP , CHIP 1UF 10V K
C291 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C293 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C301 CCUS1H471JA CAP , CHIP 470PF 50V J
C302 CCUS1H471JA CAP , CHIP 470PF 50V J
C303 CCUS1H471JA CAP , CHIP 470PF 50V J
C304 CCUS1H471JA CAP , CHIP 470PF 50V J
C305 CCUS1H471JA CAP , CHIP 470PF 50V J
C306 CCUS1H471JA CAP , CHIP 470PF 50V J
C309 CCUS1H332KC CAP , CHIP 3300PF 50V K
C310 CCUS1H332KC CAP , CHIP 3300PF 50V K
C311 CCUS1H332KC CAP , CHIP 3300PF 50V K
