Harman Kardon AVR 141/230 - Complete Electrical Parts List

COMPLETE ELECTRICAL PARTS LISTS FOR AVR 139 - AVR 141 - AVR 14
2
AVR 139 AND AVR 141 ARE IN THE SYSTEMS 13926/13928 AND 14126/14128, WITH DVD 26 AND 28
AVR 142 IS SOLD AS A SEPARATE
Parts for AVR 139 only
Ref. # Part Number
Description
V
alue
CPG1A880X BOX , OUT CARTON
CPG1A876 BOX , PAD SYSTEM13828/230
CQXSYSTEM14126/230 INSTRUCTION MANUAL ASS'Y
CJS4S004Z CORD , PIN(3P,W/R/Y)
CJS8T001Z CABLE, HDMI(2M) CBADV-005-2
CGB1A213Z BADGE , AVR139
CPB1061W BAG , POLY(ENGLISH/FRANCH) FRANCE LANGUAGE ADDED
CGUAVR139 WINDOW ASS'Y
FRONT PANEL ASSY
Ref. # Part Number
Description
V
alue
CGWAVR139/230 FRONT PANEL ASS'Y
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
V
alue
CKF9A337Z PANEL , REAR
Parts for AVR 141 only
Ref. # Part Number
Description
V
alue
CPG1A880W BOX , OUT CARTON
CPG1A876 BOX , PAD SYSTEM13828/230
CQXSYSTEM14126/230 INSTRUCTION MANUAL ASS'Y
CJS4S004Z CORD , PIN(3P,W/R/Y)
CJS8T001Z CABLE, HDMI(2M) CBADV-005-2
CGB1A221Z BADGE , AVR141
CPB1061W BAG , POLY(ENGLISH/FRANCH) FRANCE LANGUAGE ADDED
CGUAVR141/230 WINDOW ASS'Y
FRONT PANEL ASSY
Ref. # Part Number
Description
V
alue
CGWAVR141/230 FRONT PANEL ASS'Y
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
V
alue
CKF9A337Y PANEL , REAR
Parts for AVR 142 only
Ref. # Part Number
Description
V
alue
CQX1A1441Z MANUAL , INSTRUCTION
CPG1A890Z BOX , OUT CARTON
CGUAVR142/230 WINDOW ASS'Y
CGB1A222Z BADGE , AVR142
CGU2A399W WINDOW , FIP
FRONT PANEL ASSY
Ref. # Part Number
Description
V
alue
CGWAVR142/230 FRONT PANEL ASS'Y
BOTTOM CHASSIS ASS'Y
Ref. # Part Number
Description
V
alue
CKF9A337
X
PANEL , REAR
AVR 139 / 141 / 142 electrical
p
arts list for all model
s
Ref. # Part Number
Description
V
alue
CGL1A222 INDICATOR , VOLUME AVR130/230/330
CGR1A331H63 COVER , A AVR154
CGR1A332H63 COVER , B AVR154
CGU2A399W WINDOW , FIP
CGU1A318Y ORNAMENT , VOLUME AVR255
CGX1A338MBC63 CAP , VOLUME
CKC6B145S60 CABINET , TOP AVR350
CMH1A214 HOLDER , VOLUME AVR130/230/330
CMZ2A090 SHEET , VOLUME
CQB1A549Y LABEL , ATTENTION DVD48
CQB1A622 LABEL , SERIAL NO
CTB3+8JFZR SCREW
CTB4+6FFZR SCREW
CHE154 CLAMPER , ARM
CPP1A081Z BAG,POLY SET
CPS5A564 PAD , SNOW L
CPS5A565 PAD , SNOW R
CQB1A907Z LABEL , BAR CODE AVR154
CQB1A931Y LABEL , COUNTRY AVR142/230
CQS1A001 RIBON , BAR CODE SONY
(
TR-4070
)
harman/kardon
AVR 139-141-142/230 Service Manual
Page 10 of 83
