FM Antenna
AM Antenna
Video 2 A/V Inputs
Video 1 A/V Outputs
Video 1 A/V Inputs
Video Monitor Outputs
DVD A/V Inputs
Component Video Inputs (1 & 2)
Component Video Monitor Outputs
AC Power Cord
RS-232 Serial Port
Coaxial Digital Audio Inputs (1 & 2)
RS-232 Mode
The Bridge/ DMP Input
RS-232 Reset
Subwoofer Output
Front Speaker Outputs
Surround Speaker Outputs
6-Channel Inputs
Center Speaker Outputs
Switched AC Accessory Outlet
Coaxial Digital Audio Output
Optical Digital Audio Inputs (1 & 2)
Optical Digital Audio Output
CD Inputs
Tape Outputs
Tape Inputs
10
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at www.harmankardon.com
