5
AVR 156
ENGLISH
Composite Video Devices
You will need to make composite video connections from your source devices that do not
have HDMI or component video connections. You will also need to connect the source
device’s analog audio outputs to the AVR’s corresponding analog audio connectors.
AVR Composite
Video Connectors
Composite Video
Cable (not supplied)
Composite Video-Equipped
Source Device
To Composite
Video Output
Note: If you connected your Blu-ray Disc or DVD player to the AVR's DVD Component In
connectors, do not connect a source device to the AVR's composite DVD In connector.
Optical Digital Audio Devices
If your source devices have optical digital outputs, connect them to the AVR's optical
digital audio connectors. NOTE: Make only one type of digital connection (HDMI, optical
or coaxial) from each device.
AVR
Digital Audio Connectors
Optical Digital Audio
Cable (not supplied)
Optical-Equipped
Source Device
To Optical Digital
Audio Output
Coaxial Digital Audio Devices
If your source devices have coaxial digital outputs, connect them to the AVR's coaxial
digital audio connectors. NOTE: Make only one type of digital connection (HDMI, optical
or coaxial) from each device.
AVR
Digital Audio Connectors
Coaxial Digital Audio
Cable (not supplied)
Coaxial-Equipped
Source Device
To Coaxial Digital
Audio Output
Analog Audio Devices
Make analog audio connections from your source devices that do not have HDMI or digital
audio connections. If you’re connecting video sources to the AVR's DVD, Video 1 or Video
2 audio inputs, you must also connect the source device’s composite video output to the
corresponding composite video connector.
AVR Analog Audio Connectors
Stereo Audio Cable
(not supplied)
Analog Source Device
To Stereo Analog
Audio Output
Audio Recorders
Connect an analog audio recorder’s inputs to the AVR's analog audio Tape Out connectors.
You can record any analog audio input signal.
AVR Analog Audio Connectors
Stereo Audio Cable
(not supplied)
Analog Source Device
To Stereo Analog
Audio Output
Video Recorders
Connect an analog video recorder’s video input connector to the AVR's Video 2 Out
composite video connector and its audio input connectors to the AVR's Video 2 Out analog
audio connectors. You can record any composite video signal.
AVR Analog Audio
Connectors
AVR Analog Video Connectors
Analog Audio/Video
Cable (not supplied)
Analog Video
Recording Device
To Analog
Audio/Video
Record Inputs
Connections
